| FULL SPECTRUM |
- 380nm - 780 nm
- Improve active ingredient contents
|
| 2650umols-1 |
- Over 2.6 umol/J at 1000W
- Saving more energy while producing more
|
| WET LOCATION/ IP65 |
- Make planting easier
- Easily sterilized
|
| >87% LIGHT TRANSMISSION |
- With silicone conformal coating
|
| SUITABLE FOR GMP & GACP FACILITY |
|
SPECIFICATIONS:
| AMP DRAW |
8.4A @120V, 4.2A @240V, 3.6A@277V |
| WATTAGE |
1000 w |
| POWER FACTOR |
>0.9 |
| PPF |
2,650 umol/J |
| EFFICACY |
2.6 umol/J |
| BTU |
3400 BTU/h |
| DRIVER BRAND |
Moso |
| LIGHT SOURCE |
Osram 660nm + Samsung 301b or Seoul |
| DIMMING |
Daisy Chain Digital signal (RS485): 0-100%
Analog signal (0-10dc):35-100%
|
| MATERIAL |
6063 Aluminum
|
THERMAL MANAGEMENT Passive Cooling
| MOUNTING HEIGHTS |
>-6" (15.2cm.) Above Plant Canopy
|
| WARRANTY |
5 years |
| CERTIFICATIONS |
DLC & CSA Listed, Compliance with FCC/ UL/ CE/ RoHs standards
|
| IP RATING |
UL 8800, suitable for wet/damp locations, IP65 |
| AMBIENT OPERATING TEMPERATURE |
14*F to 104*F / -10*C to 40*C |
| LIFESPAN |
L90:>54,000 hrs. |
| FIXTURE DIMENSIONS |
L67.32xW49.29xH4.33in./ L1710xW1252xH110mm
|
| NET WEIGHT |
38.36 Lbs. / 17.4 Kgs |
| GROSS WEIGHT |
46.29 Lbs. / 21 Kgs. |
| PACKAGING DIMENSIONS |
L69.88xW15.55xH8.85in. / L1775xW395xH225mm |
| COVERAGE AREA |
Flower 5' x 6' Veg 7' x 8'
|
|
